• Subtype
  Gigabit Ethernet
• Ports
  20 x 10/100/1000 + 4 x combo Gigabit SFP
• Performance
  Switching capacity: 32 Gbps
  Forwarding performance (64-byte packet size): 35.7 Mpps
• Authentication Method
  RADIUS, Secure Shell (SSH), TACACS+
• Flash Memory
  32 MB flash
• MAC Address Table Size
  8K entries
• Authentication Method
  Secure Shell (SSH), RADIUS, TACACS+
• Status Indicators
  Port transmission speed, port duplex mode, power, link OK, system, link/activity
• Encryption Algorithm
  SSL
• Manufacturer
  Cisco

Camera

• Installed Size
  32 MB

Networking

• Cabling Type
  Ethernet 1000Base-T, Ethernet 100Base-TX, Ethernet 10Base-T
• MAC Address Table Size
  8K entries
• Subcategory
  network hubs and switches
• Subtype
  Gigabit Ethernet
• Form Factor
  rack-mountable
• Type
  Switch
• Connectivity Technology
  wired
• Features
  ARP support, Access Control List (ACL) support, MAC Address Notification, Multicast Storm Control, Multiple Spanning Tree Protocol (MSTP) support, Port Aggregation Protocol (PAgP) support, Port Security, Quality of Service (QoS), Rapid Spanning Tree Protocol (RSTP) support, Remote Switch Port Analyzer (RSPAN), Syslog support, Unicast Storm Control, BOOTP support, VLAN support, auto-negotiation, auto-sensing per device, auto-uplink (auto MDI/MDI-X), dynamic IP address assignment, layer 2 switching, load balancing, Broadcast Storm Control, DHCP snooping, DiffServ support, Dynamic Trunking Protocol (DTP) support, IGMP snooping, IPv6 support, Link Aggregation Control Protocol (LACP)
• Compliant Standards
  IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ah, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z, IEEE 802.1ab (LLDP), IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP)
• Ports Qty
  20
• Manageable
  Yes
• Switching Protocol
  Ethernet
• Remote Management Protocol
  HTTP, HTTPS, SSH, TFTP, Telnet, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 1, SNMP 2, SNMP 2c, SNMP 3
• Communication Mode
  full-duplex, half-duplex

Power Device

• Nominal Voltage
  AC 120/230 V
• Frequency Required
  50/60 Hz
• Power Consumption Operational
  72 Watt
• Type
  internal power supply

Miscellaneous

• Rack Mounting Kit
  optional
• Encryption Algorithm
  SSL
• MTBF
  313828 sec
• Height (Rack Units)
  1 m

Interface Provided

• Qty
  24, 4
• Connector Type
  SFP (mini-GBIC)

Environmental Parameters

• Humidity Range Storage
  10 – 95% (non-condensing)
• Min Storage Temperature
  -13 °F
• Max Storage Temperature
  158 °F
• Min Operating Temperature
  23 °F
• Max Operating Temperature
  104 °F
• Humidity Range Operating
  10 – 95% (non-condensing)

Header

• Brand: Cisco
• Product Line: Cisco Catalyst
• Model: 2960G-24TC
• Packaged Quantity: 1
• Compatibility: PC

Dimensions & Weight

• Width: 17.5 in
• Depth: 12.9 in
• Height: 1.7 in
• Weight: 10.01 lbs

Software

• Type: Cisco LAN Base software

Ports

• Type: 10/100/1000
• Qty: 20

Ports (2nd)

• Type: combo Gigabit SFP
• Qty: 4

Performance

• Type: forwarding performance (64-byte packet size), switching capacity
• Value: 32 Gbps, 35.7 Mpps

Slot Required

• Type: none

Service & Support

• Type: limited lifetime warranty

Service & Support Details

• Type: limited warranty
• Full Contract Period: lifetime

General

• Manufacturer: Cisco
