• 13th Gen Intel® Core™ i3-13100, 4C (4P + 0E) / 8T, P-core 3.4 / 4.5GHz, 12MB

• 13th Gen Intel® Core™ i5-13400, 10C (6P + 4E) / 16T, P-core 2.5 / 4.6GHz, E-core 1.8 / 3.3GHz, 20MB

• Windows 11 Pro 64

• Windows 11 Pro 64 (preinstalled with Windows 10 Pro 64 Downgrade)

Integrated Intel UHD Graphics

Up to 1x 16GB UDIMM DDR4-3200

*Two DDR4 UDIMM slots, dual-channel capable

1TB SSD M.2 2280 PCIe 4.0x4 NVMe Opal 2.0 + 1TB HDD 7200rpm 3.5"

*Up to two drives, 1x 3.5" HDD + 1x M.2 SSD

• High Definition (HD) Audio, Realtek® ALC222-CG codec

• No speakers

Optional: DVD burner (DVD±RW), SATA 1.5Gb/s, slim (9.0mm)

Optional: 3-in-1 card reader (SD, SDHC, SDXC)

Intel B760 chipset

Tower (13.6L)

145 x 294 x 340 mm

*The system dimensions may vary by configuration.

Around 5.5 kg

*The system weight may vary by configuration.

Black

• 1 x 3.5" disk bay

• 1 x slim ODD bay

• One PCIe 4.0 x16, full-height, half-length

• Two PCIe 3.0 x1, full-height, half-length

• Optional: Two M.2 slots (one for WLAN, one for SSD)

• Optional: M.2 Bracket. For installing M.2 devices, M.2 bracket kit is needed. The kit is optional, or comes with pre-configured M.2 SSD or M.2 Wifi models

• 180W Fixed 85%

• 260W Fixed 90%

• USB Calliope Keyboard, Black, English

• USB Traditional Keyboard, Black, English

USB Calliope Mouse, Black

Intel I219-V, 1x RJ45

Optional: Realtek Wi-Fi 6 RTL8852BE, 802.11ax Dual Band 2x2 Wi-Fi + Bluetooth 5.1, M.2 card

Non-vPro

• Discrete TPM 2.0, TCG certified

• Optional: Smart Cable Clip

• Kensington® Security Slot™, 3 x 7 mm

• Padlock Loop

• Optional: Chassis intrusion switch

• No fingerprint reader

• Administrator password, Power-on password, Hard disk password

• Cover presence switch

• Smart USB protection (allows keyboard / mouse only, blocks all storage devices)

Front ports:

• 2 x USB 3.2 Gen 1

• 2 x USB 3.2 Gen 2

• 1 x USB-C 3.2 Gen 1 (support data transfer and 5V@3A charging)

• 1 x headphone / mic

• 1 x microphone (3.5mm)

Optional front ports:

• 1 x card reader

Rear ports:

• 1 x HDMI 1.4b

• 1 x DisplayPort™ 1.4

• 1 x VGA

• 4 x USB 2.0 (one supports Smart Power On)

• 1 x serial (9-pin)

• 1 x Ethernet (RJ-45)

• 1 x headphone (3.5mm)

Optional rear ports:

• 1 x 2nd serial

• 1 x parallel

• 2 x PS/2

• None

*Depending on many factors, such as the processing speed of the host device, file attributes and other factors related to system configuration and your operating environment, will be slower than theoretical speed.

Full platform specifications
